At Agile Microsys, we proudly introduce the FLIR TG298, a high-performance industrial thermal temperature gun engineered for environments where extreme heat measurement is critical. Designed to go far beyond the capabilities of standard IR thermometers, the TG298 helps you visualize, measure, and document high-temperature anomalies with exceptional clarity.
Ideal for glass manufacturing, kilns, foundries, metal forges, high-heat process plants, and industrial maintenance, this thermal imager delivers accurate readings even in the most demanding operating conditions.
Powered by advanced FLIR MSX® (Multi-Spectral Dynamic Imaging), the TG298 blends visible details onto thermal imagery, making components sharper and easier to identify. With Super Resolution, thermal images captured at 160 × 120 pixels can be enhanced up to 320 × 240, allowing you to see subtle electrical, mechanical, or thermal variations effortlessly.
Capable of imaging temperatures up to 1080°C (1976°F), the TG298 ensures you detect overheating early — helping prevent breakdowns, improve maintenance planning, and increase equipment life span.
With FLIR Meterlink® app support, you can record, store, compare readings, and generate field-ready reports instantly. This makes maintenance tracking easier, faster, and more reliable for industrial teams.
Request Info
Identify Problems Quickly
Agile Microsys provides the FLIR TG298, designed for fast problem identification.Accurately measure temperatures up to 1080°C (1976°F) with a 30:1 spot size ratio and bullseye laser pointer.
Produce Crisp Thermal Images
Agile Microsys offers the FLIR TG298, Diagnose problems quickly with Flir-patented MSX image enhancement and Improve the details of native thermal images with super resolution, which allows you to upscale images to 320 × 240 (76,800 pixels) resolution.
Work with Confidence in Rugged Environments
Agile Microsys offers the FLIR TG298, The IP54 rated Flir TG298 comes complete with a built-in LED worklight for better visibility in dark or poorly lit areas, and a 2 m drop test rating for durability.
OVERVIEW
| IR Resolution | 160 × 120 Super Resolution 320 × 240 |
|---|---|
| Thermal Sensitivity_NETD | <70 mK |
| Accuracy |
±2.5% or 2.5°C (6°F) at 0°C to 50°C (33°F to 122°F ) and 100°C to 400°C (213°F to 752°F) ±3% or 3°C (7°F) at −25°C to 0°C (−13°F to 32°F) and >400°C (>752°F) |
| Field of view [FOV] | 57° × 44° |
| Image Modes | MSX® (Multi Spectral Dynamic Imaging) Visual with temperature reading |
| Display | 320 × 240, 2.4 in color LCD |
| Storage Media | 8 GB |
CONNECTIONS & COMMUNICATIONS
| Image Storage Capacity | 8 GB |
|---|---|
| Interfaces | USB 2.0, Bluetooth |
| Memory Type | Internal |
| METERLiNK | Yes |
| Saved image format | JPEG with spot temperature data |
| Storage Media | 8 GB |
| Time Lapse | Yes |
| USB | USB Type-C: data transfer/power |
| USB_Standard | USB 2.0 High Speed |
ENVIRONMENTAL
| Certifications | CE, CB, RCM, IEC60825-1, FDA, UL, CEC, NRCan |
|---|---|
| Drop test | Designed for 2 m (6.6 ft) |
| EMC | EN 61000-6-3 EN 61000-6-2 FCC 47 CFR Part 15 Class B |
| Encapsulation | IP 54 (IEC60529) |
| Humidity [operating and storage] | 0 to 90% RH (0 to 37°C (32 to 98.6°F)), 0 to 65% RH (37 to 45°C (98.6 to 113°F)), 0 to 45% RH (45 to 55°C (113 to 131°F)) |
| Operating Temperature Range | −10°C to 45°C (14°F to 113°F) |
| Radio Spectrum | ETSI EN 300 328 FCC Part 15.249 RSS-247 Issue 2 EN 301 489-1:2011 EN 301 489-17:2009 |
| Safety | CE/CB/EN61010/UL |
| Shock | 25 g (IEC 60068-2-27) |
| Storage Temperature Range | −30°C to 55°C (−22°F to 131°F) |
| Tripod Mounting | 1/4 in.-20 on handle bottom |
| Vibration | 2 g (IEC 60068-2-6) |
| Warranty | FLIR 2-10 warranty |
IMAGING & OPTICAL
| Built_in Digital Camera | Yes |
|---|---|
| Color palettes | Iron, Rainbow, White hot, Black hot, Arctic, Lava |
| Detector Pitch | 12 µm |
| Detector Type | Focal plane array (FPA), uncooled microbolometer |
| Digital image enhancement | Yes |
| Field of view [FOV] | 57° × 44° |
| Focus | Focus free |
| Image Frequency | 8.7 Hz |
| Image Modes | MSX® (Multi Spectral Dynamic Imaging) Visual with temperature reading |
| IR Resolution | 160 × 120 Super Resolution 320 × 240 |
| Laser | Class 1 laser indicates the temperature measurement area; button-activated |
| Minimum Focus Distance | 0.3 m (0.98 ft) |
| Minimum Measurement Distance | 0.26 m (0.85 ft) |
| Non_radiometric IR video recording | Yes |
| Spectral Range | 7.5 – 14 µm |
| Thermal Sensitivity_NETD | <70 mK |
MEASUREMENT & ANALYSIS
| Accuracy |
±2.5% or 2.5°C (6°F) at 0°C to 50°C (33°F to 122°F ) and 100°C to 400°C (213°F to 752°F) ±3% or 3°C (7°F) at −25°C to 0°C (−13°F to 32°F) and >400°C (>752°F) |
|---|---|
| Camera size [L x W x H] | 210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in) |
| Camera weight incl battery | 0.394 kg (13.9 oz) |
| Center spot | Yes |
| Emissivity Correction | Yes: 4 preset levels with custom adjustment of 0.1–0.99 |
| Object Temperature Range | −25°C to 1080°C (−13°F to 1976°F) |
| Spot Meter | Center spot on/off |
POWER
| Battery operating time | 5 hours continuous scanning, 4.5 hours with laser on |
|---|---|
| Battery Type | Rechargeable Li ion battery |
| Battery voltage | 3.7 V |
| Charging system | Battery is charged inside the camera |
| Charging Temperature | 0°C to 45°C (32°F to 113°F) |
| Charging Time | 3 hours to 90%, 4 hours to 100% |
USER INTERFACE
| Display | 320 × 240, 2.4 in color LCD |
|---|
GENERAL
| Form Factor | Pistol |
|---|---|
| Package Includes | TG298 Wrist Strap Lanyard Pouch USB Type-C cable Printed Documentation |
